Kyowa Test Pump T-508 (Hydraulic Pressure Testpump)

Model: T-508
Maximum Pressure: 5.0 (50) Mpa (kg/cm2)
Plunger Diameter: 22m/m
Stroke: 35m/m
Rate of  Water Suction Per Stroke: 13cc
Capacity of Water Tank: 4.5l Plastic tank
Size of Discharge Port: 1/4
Weight: 3.0kg
Dimensions LxWxH: 320x200x270m/m
Accessories: Pressure gauge 1/4PT, Pressure hose

• Install this pump between the water supply and the test pipe. Easy to supply water to pull out air in the pipe.
• Easy to operate with one hand by a check valve.
• Easy to perform maintenance check.
• Easy to carry out
• Water tank is P.P.
• Sunction valve uses stainless ball (SUS304)
